》8 ohm stereo power: 500Wx2
》4 ohm Stereo power: 800Wx2
》2 ohm Stereo power: 960Wx2
》8 ohm bridge power: 1400W
》Frequency Response: 20HZ-20KHZ±0.3dB
》THD+N: <0.05%@8Ω 1KHZ
》S/N Ratio: >93dB
》Slew Ratio: 13V/μS
》Damping Factor: >200
》Crosstalk: >60dB@8Ω 1KHZ
》Input Sensitivity: 0.775V
》Input impedance (balance/unbalance): 10KΩ/20kΩ
》Voltage gain (sensitivity:8ohm): 38dB
》Output Circuitry: Class TD
》Cooling: Air flow from front to rear
》Protection: Soft start, Dc, short circuit, over load, clip limit, over heat, progressive volume Conector
》Input: XLR-F,TRS,XLR-F,XLR-M
》Output: Two red and black binding posts Indictor
》Front panel: Front panel indicator: signal,clip,protect,power indicator,bridge,parallel power switch, volume, control knob
》Rear panel: Stereo / parallel / bridge switch, input sensitivity switch, low pass filler, high pass fillter, grounding switch
》Packing Dimensions (W*H*D): 568*525*140mm ( 2U )
